Hand Miter Saw 45 Degree Miter Cut Dual Bevel Miter Saw 7 “X12″ Small Miter Saw
Technical Parameter
| Model |
|
G4018 manual system |
| Cutting capacity (mm) |
0° |
Φ 180 ■200(W)×180(H) |
|
45° |
Φ 120 ■120(W)×110(H) | |
| Blade size (L*W*T)mm | 2360x27x0.9mm | |
| Saw blade speed (m/min) |
34/41/59/98m/min(by cone pulley) | |
| Voltage | 380V 50HZ | |
| Blade drive motor (kw) | 1.1KW | |
| Coolant pump motor(kW) | 0.04KW | |
| Work piece clamping | Hand operated jaws | |
| Saw blade tension | Manual | |
| Saw frame feeding type | Cylinder, manual | |
| Material feeding type | Manual | |
| Main drive | V-belt drive | |
| Over size (LxWxH) | 1400x700x1100mm | |
| Net weight(KG) | 300 | |
Main features
1. Our portable band saw features an aluminum-casting structure, light weight and stability.
2. Our portable band saw has the advantage of stepless speed regulation.
3. Our portable band saw is easy to use.
4. The saw bow of our portable band saw can be rotated from 0° to 45°. It is equipped with block feeder (with fixed sawing length).
10 Advantages
1. Super capability: Maximum capability 7".
2. Four Speed: The belt gear of it has four cutting speeds.
3. Quick Clamps: The quick clamps can be rotated from 0° to 45°.
4. Can be used both vertically and horizontally.
5. High-capacity due to controlled by motor.
6. The falling speed of saw bow is controlled by manual cylinder.
7. Has a sizing device (the machine will automatically stop after sawing materials).
8. With cooling system, can prolong the service life of saw blade and improve the precision of work piece.
9.The base of the roller can be move freely.
10. Equipped with a block feeder (with fixed sawing length).
